Azez

This product is approaching 'end of life'. For alternatives, please see at our 863R filter and UdiMatic

Automatically Self-Cleaning Electric Screen Filter:

The UDI AZEZ is an automatically self-cleaning filter which offers the most efficient solution to filtering water with changing dirt/waste loads or fluctuating flow rates. The self-cleaning system enables the filter cake formed to be sucked from the filter screen and large quantities of dirt/waste to be discharged without having to interrupt the filtration process. The short cleaning time of 20-30 seconds, using a minimum of rinsing water, is sufficient to clean the entire filter element, with the filtering process being maintained. Features of this unique design are the following components: An exhaust system with nozzles to suck up and discharge dirt from the filter element. A motor with worm connection, which moves the exhaust system in a continuous radial movement through the system, ensuring the entire filter element is cleaned.

The UDI Automatically Self-Cleaning Electric Screen Filters are available in a wide range for a great variety of applications. The filters are available from 2" to 14" (DN 50 mm – 350 mm) with a capacity of up to 550 m³/h. The filter surface varies: 2260 – 3560 – 5900 – 7500 cm² and a filter perforation from 400 to 10 microns. The working pressures vary from 2 to 8 bar (max. 10 bar).

Possibilities include adaptations to the water quality, using for instance an enlarged filtering surface, stainless steel (sintered) filter screen, multi-jet nozzle system and an advanced flushing program. For adaptations to quantity, all types can be joined together to form a filter unit of unprecedented capacity.
